Name of the Lab with Code: EE233 Analog Circuits and Lab
Faculty In charge: Dr. Bidhan Pramanick
List of experiment
- To perform op-amp as Inverting and Non-inverting Amplifiers
- To perform op-amp as Integrator, Differentiator
- To perform Op-amp as Summing amplifier and difference amplifier
- To perform Op-amp voltage follower circuit and observe the waveforms.
- To perform op-amp as Simple Half wave rectifier. Half wave precision rectifier. Improved half wave precision rectifier Full wave rectifier.
- To perform op-amp as Schmitt Trigger.
- To perform op-amp Mono-stable, and A-stable multivibrator Circuits
- To generate triangular and square waveforms using OP-Amp and to determine the time period Of the waveforms
- To design and construct a Wien bridge oscillator using Op-Amp.
- To Design and setup a RC phase shift oscillator using Op-Amp.
- To examine the operation of both a Colpitts& Hartley oscillator using Op-Amp.
- To perform op-amp as First order active low pass and High pass filter.
DMM
![](https://iitgoa.ac.in/wp-content/uploads/dmm-1024x430.png)
RPS
![](https://iitgoa.ac.in/wp-content/uploads/rps-1024x396.png)
DSO
![](https://iitgoa.ac.in/wp-content/uploads/DSO-1024x569.png)
AFG
![](https://iitgoa.ac.in/wp-content/uploads/AFG.png)
ASLK KIT
![](https://iitgoa.ac.in/wp-content/uploads/ASLK-KIT.jpg)
OP-AMP Trainer Kit
![](https://iitgoa.ac.in/wp-content/uploads/OP-AMP-Trainer-Kit.jpg)
